BPChem Crystalline Substructure Waterproofing Solutions
long-lasting defense against moisture
Cost Effective
Reliable
Crystalline Waterproofing Technology
Concrete is a pourous material by nature, left untreated it will suffer damage and signifcantly reduced service times. Protect your concrete from the day it is poured with BPChem Crystaseal Crystalline waterproofing solutions!
What Is Unique About The BPChem Crystaseal Admix Product?
The innovative crystalline technology within BPChem Crystaseal Admix reacts with moisture and free lime, a natural by-product of the cement hydration process. The reaction creates millions of nanocrystals which grow throughout the concrete matrix. As these crystals form, they fill and block the concrete’s capillary structure, protecting it from further water damage.
Crystalline waterproofing is an innovative technique used to prevent water penetration in concrete structures. It relies on crystalline technology, creating a network of insoluble, microscopic crystals within the concrete. Here’s how it works:
1. Application: Crystalline waterproofing can be applied either topically (to the surface of the concrete) or integrally (as part of the concrete mix design). The active ingredients typically include a blend of cementitious materials, sand, and proprietary chemicals.
2. Chemical Reaction: When exposed to water, the chemicals react with the byproducts of cement hydration (free lime). This reaction leads to the natural formation of insoluble crystals inside the concrete.
3. Crystal Formation: These needle-like crystals grow within the pores, capillaries, and micro-cracks of the concrete, sealing it and preventing water ingress. The resulting network of calcium silicate hydrate (C-S-H) crystals strengthens over time.
4. Durability: Crystalline waterproofing provides long-lasting protection against water damage and mold growth.
Why Do BPChem Crystaseal Admix Products Works So Well?
BPChem Crystaseal Admix BECOMES A PERMANENT, INTEGRAL PART OF THE CONCRETE.
1. Extremely resistant to high hydrostatic pressure
2. Increases compressive strength and freeze-thaw resistance of concrete
3. Protects reinforcement against corrosion
4. Substantially reduces time and labor associated with applying traditional waterproof coatings
5. NSF/ANSI Standard 61 certified for contact with potable water
6. Negligible effect on slump, air entrainment, plasticizers and water reducers Permeability tested as per DIN 1048
Integral Capillary Crystalline Waterproofing System
Waterproofing Admixtures
Concrete Restoration
Redefining Construction
Crystalline Waterproofing Technology Concrete is a porous material by nature, left untreated it will suffer damage and significantly reduced service times. Protect your concrete from the day it is poured with ALLCON Crysta seal Crystalline waterproofing solutions!
Two types of Crystalline products in BPChem,
- BPchem Crystaseal-Admixed and mixed while concreting
- BPChem Crystacoat surface brush applied crystalline waterproofing
WHAT is unique about the BPchem Crystaseal Admix & BPChem crystalcoat product?
The innovative crystalline technology within BPCHEM Crystaseal Admix & Crystacoat reacts with moisture and free lime, a natural by-product of the cement hydration process. The reaction creates millions of nanocrystals which grow throughout the concrete matrix. As these crystals form, they fi ll and block the concrete’s capillary structure, protecting it from further water damage.
WHY do BPChem Crystalline products works so well?
BPchem Crystalline product BECOMES A PERMANENT, INTEGRAL PART OF THE CONCRETE.
• Extremely resistant to high hydrostatic pressure
• Increases compressive strength and freeze-thaw resistance of concrete
• Protects reinforcement against corrosion
• Substantially reduces time and labor associated with applying traditional waterproof coatings
• NSF/ANSI Standard 61 certifi ed for contact with potable water
• Negligible effect on slump, air entrainment, plasticizers and water reducers
• Permeability tested as per DIN 1048
How Are BPChem Crystaseal Admix Products Added To The Concrete?
Available Products
BPChem Proof LC+ Liquid, easy integration at the batch plant, reduced risk of clumping during the mixing process, or added directly on-site.
BPChem Crystaseal Admix Powder, added directly at the batching plant or on-site with simple dosing through soluble bag packaging.
Typical Applications:
Waste Water Treatment Plants
Parking Structures
Foundation Walls
Concrete Slabs & Precast Panels
Shotcrete & Gunite Applications
Underground Water Tanks
Complete System Solutions
By taking a complete systems approach, it is easy to seal the entire building envelope in an efficient manner. Combining waterproof concrete with the right joint details provides designers with multiple options of delivering dry structures.
SIMKO – Waterstop is a strip applied hydrophilic rubber swelling waterstop for use in all kinds of cast-in-place concrete construction joints, as well as steel, concrete and thick walled PVC pipe penetrations. When exposed to water, the rubber expands, creating a compression seal within the joint or around the pipe penetration, blocking the passage of water.
